Phụ kiện khác cho máy cắt dây EDM Seibu
Phụ kiện khác | |||||
Ảnh Sản Phẩm | Code No. | Orignal P/No. | Kích thước | Vị trí | Máy cắt dây Seibu |
SE304 | Φ115/80x20 | Lower | EW-A. C. K. Mseries Ceramic isolator plate M type Φ115/80xΦ28x20H | ||
SE314 | 4440143 | OD=80 | Upper | EW-K. A. C series Ceramic feed roller Φ80xΦ42x20H | |
SE314-1 | 4208518 | OD=80.2 | Upper | EW-K. A. C series Ceramic feed roller for fine wire Φ80.2xΦ42x20H | |
SE315 | 4466186 | OD=160 | Upper | EW-F. K. C series Brake pulley | |
SE316 | 5427989 | OD=35 | Upper | EW-K series AWT-2B type / Pinch roller Φ35xΦ22×17.5H | |
SE317 | 5427844 | OD=50 | Lower | EW-K series AWT-2B type / Capstan roller Φ50xΦ10×17.5H | |
SE600 | 61x22x26 | Upper | Electric brush holder | ||
SE601 | 57x29x30 | Lower | Electric brush holder | ||
SE602 | 53x22x26 | Upper | Electric brush holder | ||
SE603 | 65x30x36 | Lower | Electric brush holder | ||
SE801 | PS313-1 | 70x40x34 | Upper | Electric brush holder | |
SE801-1 | Φ33.5×19.5 | Common | EW-F. K series Stopper for SE801. 802 | ||
SE801-2 | 4436809 | Φ18×25 | Spring | EW-F. K series | |
SE802 | PS313-0 | 40x54x34 | Lower | EW-F. K series Brush holder | |
SE802S | PS313-0 | 40x54x34 | Lower | EW-F. K series Brush holder set | |
| SE803 | 22x61x26 | Upper | EW-A5S. M series Electric brush holder | |
SE804 | Φ33xΦ13×17 | Upper | EW-A5S. M series Left ceramic pulley Ref. SE318 | ||
SE805 | 5420841 | Φ33xΦ13×10 | Lower | EW-F. K series Right ceramic pulley Ref. SE319 | |
SE806 | Φ50×20 | Lower | EW-F. K series Left capstan roller joint type Ref. SE320 | ||
SE807 | Φ50×20 | Left | EW-F. K series Right pinch roller Ref. SE321 | ||
SE808A | 4468314 | Φ42.8xΦ22×12 | Right | EW-F. K series Feed roller | |
SE808B | Φ43.8xΦ22×12 | Lower | EW-A5S series Feed roller | ||
SE809 | Φ44xΦ11×19 | Upper | EW-A5S. M series Guide roller | ||
| SE810 | 29x52x30 | Lower | EW-A5S. M series Electric brush holder | |
| SE811 | 36x65x30 | Lower | EW-A5S. M series Electric brush holder |
