Workpiece clamping system ZEROPOINT Series B
Workpiece clamping system ZEROPOINT Series B
| Template | Size |
| ZP-023050 | Features: Clips moderately small workpieces in the up and down direction, and can finely adjust the ZX, ZY plane. The lower level of the workpiece is +5 mm Clamping range: small medium workpiece up to 5kg Including: ZP-023010 BASE BASE – 155/8.5 1 pc ZP-023051 CLAMP B -100 / 8.5 1 pc |
| ZP-023060 | Functions: Clamps small round or medium cube workpieces in the up and down direction, and the ZX, ZY plane can be finely adjusted. Clamping range: small medium workpiece up to 4kg Consists of: ZP-023010 BASE B – 155 /8.5 1 pc ZP-023062 CLAMP B – 62 / 8.5 1 pc |
| ZP-023070 | Features: Clamps moderately small workpieces in the up and down direction, and can finely adjust the ZX, ZY plane. Lower level of workpiece is 0 or + 5 mm Clamping range: medium workpiece as small as 4kg Consists of: ZP-023010 BASE B – 155 / 8.5 1 pc ZP-023071 Clamping Head B 1 pc ZP-029302 Spacer for Clamp B – 12.5 / 8.5 1 pc |
| ZP-023080 | Features: Clamps moderately small workpieces in the up and down direction, and can finely adjust the ZX, ZY plane. Lower level of workpiece is 0 or + 5 mm Clamping range: medium workpiece as small as 4kg Consists of: ZP-023010 BASE B – 155 / 8.5 1 pc ZP-023081 Clamping Head B-R 1 pc ZP-029302 Spacer for Clamp B – 12.5 / 8.5 1 pc |
| ZP-023090 | Features: Clamps moderately small workpieces in the up and down direction, and can finely adjust the ZX, ZY plane. Lower level of workpiece is 0 or + 5 mm Clamping range: medium workpiece as small as 4kg Consists of: ZP-023010 BASE B – 155 / 8.5 1 pc ZP-023091 Clamping Head B-L 1 pc ZP-029302 Spacer for Clamp B – 12.5 / 8.5 1 pc |
| ZP-023100 | Features: Good adjustment in ZX, ZY plane after clamping a medium sized workpiece. The junction between the vice layer and the workpiece is made in a downstream configuration, preventing the workpiece from falling out of place. Clamping range: small to medium workpiece 3kg (0~100mm ) Consist of: ZP-023010 BASE B – 155 / 8.5 1 pc ZP-023101 VISE B – 100 / 15 – R 1 pc |
| ZP-023110 | Features: Good adjustment in ZX, ZY plane after clamping a medium sized workpiece. The junction between the vice layer and the workpiece is made in a downstream configuration, preventing the workpiece from falling out of place. Clamping range: medium workpiece as small as 3kg (0~100mm) Consists of: ZP-023010 BASE B – 155 / 8.5 1 pc ZP-023102 VISE B – 100 / 15 – L 1 pc |
| ZP-033100 | Features: Good adjustment in ZX, ZY plane after clamping a medium sized workpiece. The junctions between the vise and the workpiece are made in the downstream profile, preventing the workpieces out of the ot position. Fine adjustment in C direction can use adjustment bolts. Clamping range: medium workpiece as small as 3kg (0~100mm) Consists of: ZP-024030 TILTING BASE 1 pc ZP-033101 VISE BN-100/15-R 1 pc |
