In connection with an external pressure transmitter, the PNI pressure sensor with analogue input can be used to detect soiling of a filter. Moreover, the sensor is often used for part seat monitoring in machine tools. The sensor provides reliable differential pressure measurement even between remote measuring points, thus reducing wiring complexity.
The two freely configurable switching outputs of the pressure switch can be continuously adjusted using an analogue input signal. The clearly readable display indicates either the input pressure, the output pressure or the differential pressure.
Product | Measuring range | Process connection | Output signal | Electrical design | Medium temperature |
PNI024 | 0… 10 bar | G 1/4 internal thread | | PNP / NPN | -25… 80 ° C |
PNI023 | 0… 25 bar | G 1/4 internal thread | | PNP / NPN | -25… 80 ° C |
PNI022 | 0… 100 bar | G 1/4 internal thread | | PNP / NPN | -25… 80 ° C |
PNI021 | 0… 250 bar | G 1/4 internal thread | | PNP / NPN | -25… 80 ° C |
