| Dimensions (mm) | 6 | 10 | 16 | 20 | ||
| Guide unit size | 5 | 7 | 9 | 12 | ||
| Fluids | Gas | |||||
| Impact | Two effects | |||||
| Level port size | M5 x 0.8 | |||||
| Minimum operating pressure | 0.15 MPa | 0.06 MPa | 0.05 MPa | |||
| Maximum operating pressure | 0.7 MPa | |||||
| Destructive pressure | 1.05 MPa | |||||
| Fluid temperature and environment | Without sensor: -10 to 700C (no freezing) With sensor: -10 to 600C (no freezing) | |||||
| Piston speed | 50 to 500 mm/s | |||||
| Allowable Momentum (J) | 0.0125 | 0.025 | 0.05 | 0.1 | ||
| Lubricant | No oil needed | |||||
| Damping | Rubber shock absorbers | |||||
| Cruise tolerance | + 01.0 | |||||
| Options | Contact sensor: D-A9 Electronic sensors: D-M9, D-M9 | |||||
| Sensor | ||||||
