| Focal length (mm): | 50 |
| Sensor size: | 1" |
| Pixel size (µm): | 4 |
| Attachment: | C-mount |
| Iris control: | Manual |
| Iris Band (F-Stop): | 1,4 - 16 |
| Lens Type: | Fixed Focal Lens |
| Wavelength Range: | Broad Band Coating (380nm - 1000nm), VIS (380nm - 780nm) |
| Focus range (m): | 0,5 - ∞ |
| Focus control: | Manual |
| Shooting range in MOD, horizontal (mm): | 121,8 |
| Shooting range in MOD, vertical (mm): | 91,3 |
| Resolution, Center: | 120 |
| Resolution, Angle: | 80 |
| Distortion (TV) (%): | 0,05 |
| Refocus in the air (mm): | 14,8 |
| Filter size (mm): | M40,5 x P0,5 |
| Dimensions (mm): | Ø50 X 48 |
| Weight (g): | 170 |
| Temperature range (℃): | -10°C - +50°C |
| Series: | HC-V |
| Register: | ITS/Traffic Control, Machine Vision |
