- 经认证符合 IEC 60947-5-3、ISO 13849-1、IEC 62061 和 IEC 61508
- 确保操作员和机器安全
- 电子故障安全传感器无需特殊执行器
- 将传感器连接到安全 PLC 或安全 AS-i 模块
| Product Code | Size | Sensor range | Permissible zone | Output function | Output |
| GF711S | M12 x 1 / L = 70 mm | | 0.5…4 mm | 2 x OSSD (A1 and A2) | DC PNP |
| GG712S | M18 x 1 / L = 70 mm | | 1…5 mm | 2 x OSSD (A1 and A2) | DC PNP |
| GG711S | M18 x 1 / L = 70.5 mm | | 1…8 mm | 2 x OSSD (A1 and A2) | DC PNP |
| GM705S | 40 x 40 x 66 mm | | 4…20 mm | 2 x OSSD (A1 and A2) | DC PNP |
| GM701S | 40 x 40 x 66 mm | | 10…15 mm | 2 x OSSD (A1 and A2) | DC PNP |
| GG507S | M18 x 1 / L = 90.5 mm | | 1…4 mm | clock signal | DC |
| GI712S | M30 x 1.5 / L = 70 mm | | 1…10 mm | 2 x OSSD (A1 and A2) | DC PNP |
| GI701S | M30 x 1.5 / L = 80 mm | | 6…12 mm | 2 x OSSD (A1 and A2) | DC PNP |
| GG505S | M18 x 1 / L = 90 mm | | 3…6 mm | clock signal | DC |
| GI711S | M30 x 1.5 / L = 70 mm | | 1…15 mm | 2 x OSSD (A1 and A2) | DC PNP |
| GI505S | M30 x 1.5 / L = 80 mm | | 6…12 mm | clock signal | DC |
| GM505S | 40 x 40 x 66 mm | | 10…20 mm | clock signal | DC |
| GM504S | 40 x 40 x 66 mm | | 10…15 mm | clock signal | DC |
| GG851S | M18 x 1 / L = 86.5 mm | | 10… mm | 2 x OSSD (A1 and A2) | DC PNP |
