Product Code | Sensor range | Frequency conversion | Output function | Output | Size |
IGR212 | 8 mm flush mountable | 2 Hz | usually open | DC PNP | M18 x 1 / L = 40 mm |
IFR212 | 4 mm flush mountable | 2 Hz | usually open | DC PNP | M12 x 1 / L = 40 mm |
IIR212 | 15 mm flush mountable | 2 Hz | usually open | DC PNP | M30 x 1.5 / L = 45 mm |
IFR200 | 4 mm flush mountable | 2 Hz | usually open | DC PNP | M12 x 1 / L = 60 mm |
IGW202 | 8 mm flush mountable | 2000 Hz | usually open | DC PNP | M18 x 1 / L = 65 mm |
IFW204 | 4 mm flush mountable | 2000 Hz | usually open | DC PNP | M12 x 1 / L = 65 mm |
IGR200 | 6 mm flush mountable | 2 Hz | usually open | DC PNP | M18 x 1 / L = 70 mm |
IGR203 | 6 mm flush mountable | 50 Hz | usually open | DC PNP/NPN | M18 x 1 / L = 40 mm |
IIW202 | 15 mm flush mountable | 2000 Hz | usually open | DC PNP | M30 x 1.5 / L = 65 mm |
IM5126 | 40 mm non-flush mountable | 200 Hz | additional | DC PNP | 40 x 40 x 54 mm |
IGR206 | 6 mm flush mountable | 50 Hz | usually open | DC PNP/NPN | M18 x 1 / L = 40 mm |
IM5124 | 20 mm flush mountable | 200 Hz | additional | DC PNP | 40 x 40 x 54 mm |
IGR204 | 6 mm flush mountable | 50 Hz | usually open | DC PNP/NPN | M18 x 1 / L = 40 mm |
IM5119 | 20 mm flush mountable | 200 Hz | usually open | DC PNP | 40 x 40 x 54 mm |
IEW200 | 3 mm flush mountable | 2000 Hz | usually open | DC PNP | M8 x 1 / L = 40 mm |
IM5129 | 40 mm non-flush mountable | 200 Hz | usually open | DC PNP | 40 x 40 x 54 mm |
IGR205 | 6 mm flush mountable | 50 Hz | usually open | DC PNP/NPN | M18 x 1 / L = 40 mm |
