대학 요록IFM电容式传感器（适用于非金属容器）
| Product Code | Sensor range | Output function | Output | Size | Connection |
| KG6000 | 0.5…30 mm non-flush mountable | normally open / normally closed; (selectable) | DC PNP | M18 x 1 / L = 92.5 mm | Connector M12 |
| KI6000 | 0.5…40 mm non-flush mountable | normally open / normally closed; (selectable) | DC PNP | M30 x 1.5 / L = 92 mm | Connector M12 |
| KI5300 | 0.5…40 mm non-flush mountable | usually open | DC NPN | M30 x 1.5 / L = 92 mm | 2 m Cable-PUR |
| KI5085 | 8 mm flush mountable | normally open / normally closed; (selectable) | DC PNP | M30 x 1.5 / L = 90 mm | Connector M12 |
| KG5309 | 0.5…30 mm non-flush mountable | usually open | DC PNP | M18 x 1 / L = 92.5 mm | Connector M12 |
| KI5303 | 0.5…40 mm non-flush mountable | usually open | DC PNP | M30 x 1.5 / L = 92 mm | 2 m Cable-PUR |
| KI5083 | 20 mm non-flush mountable | normally open / normally closed; (selectable) | DC PNP | M30 x 1.5 / L = 90 mm | Connector M12 |
| KI5309 | 0.5…40 mm non-flush mountable | usually open | DC PNP | M30 x 1.5 / L = 92 mm | Connector M12 |
| KI5301 | 0.5…40 mm non-flush mountable | normally closed | DC PNP | M30 x 1.5 / L = 92 mm | 2 m Cable-PUR |
| KI5302 | 0.5…40 mm non-flush mountable | normally closed | DC NPN | M30 x 1.5 / L = 92 mm | 2 m Cable-PUR |
| KG5311 | 0.5…9 mm quasi flush | usually open | DC PNP | M18 x 1 / L = 92.5 mm | Connector M12 |
| KI5311 | 0.5…24 mm quasi flush | usually open | DC PNP | M30 x 1.5 / L = 92 mm | Connector M12 |
| KQ6001 | 12 mm non-flush mountable | normally open / normally closed; | DC PNP/NPN | 20 x 14 x 48 mm | 2 m Cable-PUR |
